Subaru-Robin EA190V (5.5 HP; 4.1 kW) general-purpose engine with vertical shaft specifications: horsepower and torque, cylinder compression, valve clearance, oil type and capacity, and service data.
EA190V Engine Specifications
Engine model | EA190V |
Engine type | 4-stroke, OHV, single-cylinder |
Displacement | 189 cm3, (11.53 cu·in) |
Max. horsepower | 5.6 PS (4.1 kW; 5.5 HP) at 3,600 rpm |
Max. torque | 11.2 N·m (1.1 kg·m, 8.3 ft·lb) at 2,500 rpm |
Cooling system | Forced air |
Air cleaner | Foam (Optional Paper) |
Lubricating system | Splash type |
Ignition system | Capacitance discharge type |
Fuel system | Float type carburetor |
Fuel consumption | 395 g/kWh |
Fuel tank capacity | 1.0 L (0.26 US. gal. 0.22 Imp. gal.) |
Fuel used | Unleaded gasoline (octane number 86 or higher) |
Starting system | Recoil starter |
Stopping system | Ignition primary circuit ground |
Governor | Centrifugal flyweight type |
PTO shaft rotation | Counterclockwise view from P.T.O. side |
Dimensions (L x W X H) | 425 x 360 x 290 mm (16.7 x 14.2 x 11.4 in) |
Dry weight | 14.0 kg (30.9 lbs) |
FAQ ea190v oil type
What is the oil capacity of the ea190v?
Oil Capacity EA190V ……. 20 oz (600cc) 2. Re-install the drain plug before refi lling oil. 3. Oil may need to be changed more often if operating in dusty or hot environments. Page 18 • Foam Element Remove the element and wash it in a solution of mild detergent and warm water. Then rinse the element thoroughly in clean water.
What is the Subaru ea190v pressure washer?
Specifically, this model makes use of what’s known as an ea190v engine. It’s known for having a high oil capacity, a big oil, and fuel tank capacity, and a vertical chain-driven OHC. What Are The Subaru ea190V Pressure Washer Parts?
What kind of engine does a Subaru Robin ea190v have?
The Subaru-Robin EA190V is a 189 cc (11.53 cu-in) single-cylinder air-cooled 4-stroke internal combustion general-purpose gasoline engine with vertical shaft manufactured by the Industrial Products division of Subaru Corporation under the Subaru Industrial Power Products brand name (other names: Robin, Subaru-Robin and Wisconsin Robin).
What kind of oil do you use in a 4-stroke?
Page 12 • Use 4-stroke automotive detergent oil of API service class SE or higher grade. • Select the viscosity based on the air temperature at the time of operation as shown in the table. Oil Capacity EA190V ……. 20 oz (600cc) Upper Mark Oil Dipstick Lower Mark…
Fixing a Subaru Pressure Washer w/ Electric Start – Oil leak? Or is it gas?
Subaru EA190V Pressure Washer Start-Up
